China Sodium Hypochlorite Generator manufacturer

Sea Water Electrolysis Sodium Hypochlorite Generator For Power Plant 20Kg/h

Product Details:
Place of Origin: China
Brand Name: geemblue
Certification: ISO9001 CE ATEX
Model Number: GBS-20K-NACLO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 170000 ~300000 / SET
Packaging Details: wooden case
Delivery Time: 45 works day
Supply Ability: 30 set/ month

Detail Information

Chlorine Capacity: 20Kg/h Output: 2500~4000L/h
Concentration: 5000~8000 Ppm Salt Consumption: 3.5kg/kg Cl2
Power Consumption: 4kwh/kg Cl2 Additive: Food Grade Salt
Feed Brine Concentration: 2.5~3% Feed Water Requirement: Tap Water
Cell Arrangement: Horizontal H2 Production Amount: 0.35m3/kg Cl2
High Light:

20Kg/h Sodium Hypochlorite Generator


Electrolysis Sodium Hypochlorite Generator

Product Description

Sea water electrolysis sodium hypochlorite generator for Power plant



Brief Introduction


The GEEMBLUE EC system generates a 0.8 % sodium hypochlorite solution through the electrolysis of salt water , consuming only water, salt and electricity. By producing hypochlorite on-site and on-demand, the system eliminates concerns associated with transportation and storage of chlorine gas or commercial sodium hypochlorite solutions, making it ideal for any medium to large scale application requiring chlorination.


Sodium hypochlorite turn into hypochlorous acid by hydrolysis in water, and turn into nascent oxygen [O] in further step, which having ultra strong oxidation to effect the protein of thalli and virus, and terminate pathogenic microorganisms. Besides that, during the reaction of hypochlorous acid, it’s not only having effects on cell wall and viral coat, but due to its small volume and no electrical charge, it’s also permeate into germ or virus generate oxidation reaction with the organic polymer like protein, nucleic acid and enzyme, and thus to kill pathogenic microbes. What’s more, the chlorine ion generated by hypochlorous acid will change the osmotic pressure significantly, cause death of cell by lost of activity.



System Process


The operation of the ClorTec electrochlorination system is straightforward:
– Influent water is passed through a water softener to reduce hardness therefore reducing the scaling of electrodes and lengthening the intervals between cleanings
– Using softened water, salt is dissolved in a tank to form a concentrated brine solution
– The diluted brine solution is passed through an electrolytic cell that, using DC current from a rectifier, electrolyzes the diluted brine into a 0.8% solution of sodium hypochlorite
– The 0.8% hypochlorite solution flows into a storage tank
– Hydrogen, the only byproduct of the process, is safely vented to the atmosphere




  GTL-5000 GTL-8000 GTL-10000 GTL-15000 GTL-20000
Chlorine Capacity 5Kg/hr 8Kg/hr 10Kg/hr 15Kg/hr 20Kg/hr
Water treatment Capacity(At 1ppm dosing) 100mld 160MLD 200MLD 300MLD 400MLD
Salt Consumption 3.5kg/kg Cl2 3.5kg/kg Cl2 3.5kg/kg Cl2 3.5kg/kg Cl2 3.5kg/kg Cl2
Power Consumption 4.0kw/ kg Cl2 4.0kw/ kg Cl2 4.0kw/ kg Cl2 4.0kw/ kg Cl2 4.0kw/ kg Cl2
Concentration of HYPO 5000~8000ppm 5000~8000ppm 5000~8000ppm 5000~8000ppm 5000~8000ppm
Production Flow Rate 625~1000 L/hr 1000~1600L/hr 1250~2000L/hr 1875~3000L/hr 2500~4000L/hr




– Ensures a lower carbon footprint
– Requires less salt, reducing salt levels in product water and discharge to the overall environment
– Requires less salt, reducing the number of delivery trucks on the road and lowering CO2 emissions
– Increases efficiency, resulting in significant operational savings
– An easy to operate and maintain solution — clear cells enable simple visual inspection



Sea Water Electrolysis Sodium Hypochlorite Generator For Power Plant 20Kg/h 0




Chlorination of potable water supplies
Food washing / processing treatment
Dairies / Breweries cleaning in place (CIP)
Cooling tower biocide treatment
Secondary disinfection
Industrial chlorination treatments
Swimming & Spa pool disinfection
